追踪分析

source:
  otel_traces_source:
    #record_type: event  # Add this when using Data Prepper 1.x. This option is removed in 2.0
    ssl: true
    sslKeyCertChainFile: "/full/path/to/certfile.crt"
    sslKeyFile: "/full/path/to/keyfile.key"
    authentication:
      http_basic:
        username: "my-user"
        password: "my_s3cr3t"

otel-trace-pipeline:
  # workers is the number of threads processing data in each pipeline.
  # We recommend same value for all pipelines.
  # default value is 1, set a value based on the machine you are running Data Prepper
  workers: 8
  # delay in milliseconds is how often the worker threads should process data.
  # Recommend not to change this config as we want the entry-pipeline to process as quick as possible
  # default value is 3_000 ms
  delay: "100"
  source:
    otel_traces_source:
      #record_type: event  # Add this when using Data Prepper 1.x. This option is removed in 2.0
      ssl: false # Change this to enable encryption in transit
      authentication:
        unauthenticated:
  buffer:
    bounded_blocking:
       # buffer_size is the number of ExportTraceRequest from otel-collector the data prepper should hold in memeory.
       # We recommend to keep the same buffer_size for all pipelines.
       # Make sure you configure sufficient heap
       # default value is 512
       buffer_size: 512
       # This is the maximum number of request each worker thread will process within the delay.
       # Default is 8.
       # Make sure buffer_size >= workers * batch_size
       batch_size: 8
  sink:
    - pipeline:
        name: "raw-trace-pipeline"
    - pipeline:
        name: "entry-pipeline"
raw-pipeline:
  # Configure same as the otel-trace-pipeline
  workers: 8
  # We recommend using the default value for the raw-pipeline.
  delay: "3000"
  source:
    pipeline:
      name: "entry-pipeline"
  buffer:
      bounded_blocking:
         # Configure the same value as in entry-pipeline
         # Make sure you configure sufficient heap
         # The default value is 512
         buffer_size: 512
         # The raw processor does bulk request to your OpenSearch sink, so configure the batch_size higher.
         # If you use the recommended otel-collector setup each ExportTraceRequest could contain max 50 spans. https://github.com/opensearch-project/data-prepper/tree/v0.7.x/deployment/aws
         # With 64 as batch size each worker thread could process upto 3200 spans (64 * 50)
         batch_size: 64
  processor:
    - otel_traces_raw:
    - otel_traces_group:
        hosts: [ "https://:9200" ]
        # Change to your credentials
        username: "admin"
        password: "admin"
        # Add a certificate file if you are accessing an OpenSearch cluster with a self-signed certificate
        #cert: /path/to/cert
        # If you are connecting to an Amazon OpenSearch Service domain without
        # Fine-Grained Access Control, enable these settings. Comment out the
        # username and password above.
        #aws_sigv4: true
        #aws_region: us-east-1
  sink:
    - opensearch:
        hosts: [ "https://:9200" ]
        index_type: trace-analytics-raw
        # Change to your credentials
        username: "admin"
        password: "admin"
        # Add a certificate file if you are accessing an OpenSearch cluster with a self-signed certificate
        #cert: /path/to/cert
        # If you are connecting to an Amazon OpenSearch Service domain without
        # Fine-Grained Access Control, enable these settings. Comment out the
        # username and password above.
        #aws_sigv4: true
        #aws_region: us-east-1
service-map-pipeline:
  workers: 8
  delay: "100"
  source:
    pipeline:
      name: "entry-pipeline"
  processor:
    - service_map_stateful:
        # The window duration is the maximum length of time the data prepper stores the most recent trace data to evaluvate service-map relationships.
        # The default is 3 minutes, this means we can detect relationships between services from spans reported in last 3 minutes.
        # Set higher value if your applications have higher latency.
        window_duration: 180
  buffer:
      bounded_blocking:
         # buffer_size is the number of ExportTraceRequest from otel-collector the data prepper should hold in memeory.
         # We recommend to keep the same buffer_size for all pipelines.
         # Make sure you configure sufficient heap
         # default value is 512
         buffer_size: 512
         # This is the maximum number of request each worker thread will process within the delay.
         # Default is 8.
         # Make sure buffer_size >= workers * batch_size
         batch_size: 8
  sink:
    - opensearch:
        hosts: [ "https://:9200" ]
        index_type: trace-analytics-service-map
        # Change to your credentials
        username: "admin"
        password: "admin"
        # Add a certificate file if you are accessing an OpenSearch cluster with a self-signed certificate
        #cert: /path/to/cert
        # If you are connecting to an Amazon OpenSearch Service domain without
        # Fine-Grained Access Control, enable these settings. Comment out the
        # username and password above.
        #aws_sigv4: true
        #aws_region: us-east-1
